The electronic switch shown in the figure is composed of a NAND gate, which generates a symmetrical square wave to control the working state of two transistor transistors, diode allowing them to alternately amplify their input signals. The mixed signal output through the capacitor is connected to the Y-axis output of the oscilloscope diode
