Bidirectional rectifier diode BAT54S 2

2、 Parameters and specifications of BAT54S

Maximum DC reverse voltage: 30V

Maximum average rectified current: 200mA

Maximum peak reverse current: 0.5A

Working temperature range: -65 ℃~+150 ℃

Packaging form: SOT-23

3、 Application of BAT54S

BAT54S is commonly used in rectification, protection, voltage limitation, and other aspects of electronic circuits.diode For example:

Reverse protection in circuits: In electronic circuits, it is often necessary to provide reverse protection to the components in the circuit to prevent damage caused by excessive reverse voltage. At this point, BAT54S can be used as a reverse protection diode. When the reverse voltage exceeds its maximum rated value, BAT54S will limit the voltage below its maximum rated value to protect the devices in the circuit.

Rectification in the circuit: BAT54S can serve as a rectifier diode in the circuit, converting alternating current into direct current. For example, in an audio amplifier, it is necessary to remove the AC component of the input signal and retain the DC component. In this case, BAT54S can be used as a rectifier diode
