4. Appearance size

The external dimensions refer to the external dimensions and pin arrangement of the voltage regulator diode. When selecting, it should be determined based on the board layout of the circuit.

4、 Application of voltage regulator diode

Zener  diodes are widely used in power supplies, amplifiers, computers, communications, and other fields. Here are some common application scenarios:

1. Voltage stabilizing power supply

Zener diodes can be applied in linear regulated power supplies to achieve stable control of output voltage. Stabilized power supplies are widely used in various electronic devices, such as computers, communication equipment, audio equipment, etc. diode

2. Reference voltage source

Zener  diodes can be used in reference voltage sources to achieve precise control of the reference voltage in circuits. Reference voltage sources are widely used in fields such as analog circuits and sensors.

3. Voltage limiter

Zener  diodes can be used in voltage limiters to protect other components in the circuit from damage caused by overvoltage. Voltage limiters are widely used in fields such as automotive electronics and power electronics.

4、 Faults and Solutions of Zener Diodes

1. Short circuit fault

Zener diode short circuit fault refers to a low resistance short circuit phenomenon between the input and output of the Zener diode. When such a fault occurs, the voltage regulator diode cannot function properly.

Solution: Check if the pins of the voltage regulatordiode are short circuited, and if the load on the output terminal of the voltage regulator diode is too large, causing the voltage regulator diode to be unable to withstand excessive load current. If the voltage regulator diode is damaged, it needs to be replaced with a new one.

2. Open circuit fault

The open circuit fault of a voltage regulator diode refers to the phenomenon of a high resistance open circuit between the input and output of the voltage regulator diode. When such a fault occurs, the voltage regulator diode cannot function properly.

Solution: Check if the pins of the voltage regulator diode have poor contact, and if the voltage regulator diode has been damaged internally due to static electricity. If the voltage regulator diode is damaged, it needs to be replaced with a new one.
